800 Tons15 layers Hot Press Machine
Automict Plywood Hot Press MachineAutomatic multi layers plywood hot pressing ma
Description
Automict Plywood Hot Press Machine
Automatic multi layers plywood hot pressing machine with loading and unloading, the whole plywood hot pressing line, no need any worker, it is totally automatic, high efficiency and save labor cost.
This hot pressing machine has a maximum of 65 layers, so it will press up to 65 sheets of plywood at one time.machine with auto loading and unloading, so it will automatically loading plywood into the auto infeeder, and the auto infeeder will convey plywood to hot press machine, after pressed plywood, the device will automatic convey pressed plywood out and automatic stacking it. Very conveniently.
1.High efficiency and high output with many layers of presses
2.Equipped with intelligent temperature control system to eliminate bubble plate and carbonization.
3.Nitrogen accumulation, fast closing speed
4.Keep the pressure balanced and stable, eliminate the thick and thin phenomenon
5.Can be customized according to customer needs
6.Up to 50 openings for large capacity
7.Easy to use press user interface
8.The shortest press open time in the market
| Parameter Item | FDBY21-15C-800T | Board Feeding Machine (15th) | Board Unloading Machine (15th) |
| Overall dimensions | 5650 × 1405 × 4750 mm | 4220 × 2020 × 5500 mm | 4220 × 1000 × 5730 mm |
| Total weight | 85 T | 11 T | 7 T |
| Nominal Pressure | 800 T | / | / |
| Number of layers | 15 layers | 15 layers | 15 layers |
| Opening distance | 70/80 mm | 70/80 mm | 70/80 mm |
| Panel Size | 1350 × 2700 × 52 mm | / | / |
| Plate thickness | 52 mm | / | / |
| Number of boards | 16 pcs | / | / |
| Main oil cylinder of press | φ260 mm × 6 pcs | φ90 2300 mm × 2 pcs | φ90 ×2700 mm × 2 pcs |
| Press (Lifting cylinder) | φ120 mm × 2 pcs | / | / |
| Work schedule | 1100 mm | 2150 mm | 2550 mm |
| Low-pressure pump | 11 kw | / | / |
| High-pressure pump | 7.5 kw | / | / |
